Unraid Windows 10vm- Guide : Unraid is a file server system based on Slackware Linux.

Unraid allows you to create a “network” of hard drives and share drives across the LAN for all users to access files on those drives. To help fight against the physical drive failure, unraid allows the inclusion of a gender unit used to hold parity bits of information for all the other data drives. This information can reconstruct the data on a dream if it needs to be replaced.

The benefits of unRAID compared to other systems such as FreeNAS are:

  • Possibility of having a size of disks in the array (RAID typically requires having all system disk is the same physical size)
  • Ability to dynamically add players to the table as they are acquired – most RAID arrays are susceptible to the “growth.” The operation usually involves a full back up before attempting to develop the picture. If you have 5 TB of data, it’s likely not something you’re going to try!
  • Non-data striping or parity – usually, the information data and equality in a RAID is striped across the disks, which means parts of each file are stored on different disks. In unRAID, the files are stored on a single contiguous drive. This means that if there is a catastrophic problem (e.g., multiple industries fail), you can probably retrieve the available disc information.

The following are some drawbacks to unRAID:

  • Certain restrictions on the material support – see the hardware compatibility page.
  • It’s not free (for three discs) or open-sources
  • Since the data are not “striped” across multiple disks, read performance is limited to the individual drive’s speed. In full RAID implementations, data can be read faster than a single drive’s performance because many readers are simultaneously accessible, aggregation, and playback performance.

So, we’ll discuss how to install windows 10vm unraid, what to do if unraid windows 10vm has no sound, how to remote access unraid windows 10vm, and setup unraid windows 10vm.

Unraid Windows 10vm- Guide
Unraid Windows 10vm- Guide

STEP 1: SETUP THE VM WITHOUT ANY PASSED THROUGH HARDWARE

I. DOWNLOAD A COPY OF WINDOWS 10 ISO which is the latest one

Copy to share on our unRAID system (isos default)

II. GET CHEAP WINDOWS 10 LICENSE

You can find cheap licenses in various markets like Amazon.

III. INSTALL DRIVERS OF VIRTIO

On unpaid in Settings / VM Manager, we can download the ISO Laster virtio driver for Windows.

IV. INSTALL THE SYSTEM

CPUS

UnRAID uses the first vCPUs (first CPU 0) to calculate, it is best to leave them free.

When assigning logical CPUs (threads) to a virtual machine, it is best to ensure that we give both pairs hyperthreaded of each core.

RAM

  • Always make sure that we have enough RAM to our server and the virtual machine.
  • For Windows 10, we need a minimum of 2 GB.
  • To be sure, 8GB should be adequate.

BIOS

  • Leave the BIOS OVMF game unless we cannot install the operating system with this parameter.
  • If through a GPU, the GPU must support EFI to use OVMF.
  • If we know that our GPU does not support EFI, use sea bios.

HYPER V

Hyper-V must be set to Yes.

OS INSTALL

The ISO installing operating system must be set on our Windows 10 ISO location.

OS install CD-ROM Bus must be set to FDI.

DRIVER VIRTIO

ISO VIRTIO driver must be set to the driver location VIRTIO we downloaded.

VIRTIO pilot CD-ROM bus must be set to IDE.

vDisk

We do not need a large vDisk; we will store most of the data on the table with the players and symbolic links.

INSTALLATION

  • When we need to choose a disk to install Windows, we see no disk in the list.
  • To see the vDisk, install a driver.
  • Click Load Driver and Browse.
  • Select the virtio-win CD / NVR / w10 / amd64 and click Next.
  • We will be able to see the vDisk and complete the installation.

V. POST INSTALL TASKS

CONFIGURATION WINDOWS BOOT

Setup Up Region, keyboard configuration, Network (skip), user settings, and Cortana privacy settings at boot.

DRIVERS virtio

  • Go to the Device Manager; we will see three devices that do not have a driver in other devices.
  • The display adapter is a driver to be installed as well.
  • Click the Update Driver and Browse my computer for driver software.
  • Look at the location of virtio CDRom and click next to install the driver.
  • Repeat for each missing driver.

GUEST-agent installation

Go to VIRTIO-winning drive and install agent gpu / qemu-ga-x64.msi.

VIDEO SETTINGS

Now we can change the video resolution of up to Display Settings.

SOFTWARES

We can download a bunch of packages at the same time, thanks to services like Ninite.

We can turn off windows ten phoning home with our data by installing a tool like Windows Privacy Tweaker.

VI. CONNECTING THE REMOTE VM

  • VLC is used by default on unRAID. This is not more powerful.
  • Using a like Splash top or TeamViewer significantly improves performance.
  • For a distance function with Splash top Remote using a free account, we need to put a router VPN on our server to access it locally.

PIMP SETTINGS

We need to change some Windows settings for a better experience VM.

POWER OPTIONS

Choose the power button to turn off the quick tour starts. In Choose or customize a high-performance diet plan, click then go to Modify hard drive and turn off / disable the hard drive and the USB settings AFTER / USB selective suspend setting/adjustment. When finished, you can turn off the display as well.

DISABLE INDEXING

It is useful to reduce unnecessary IO on the vdisk. Go to services.msc and stop the Windows Search service and disable its properties.

Now, run Cmd as administrator and type powercfg -h off. To disable disk fragmentation, go to the properties of the local drive and tools / optimize. Then go to change settings and uncheck Run on a schedule.

VII. HOW TO USE SYMLINKS TO MAKE IT EFFECTIVE

Create a share with SMB allows. Map a network drive and folder, relocate the document. If you cannot find the Windows type, the address of the server \\ [ip] \ in the file explorer. Edit the related symbolic link (e.g., downloads).

VIII. INSTALL A VIRTUAL SOUND CARD

You must modify the XML code in the VM at the bottom of the file video-tag.

STEP 2: PASS THROUGH THE HARDWARE NEEDED

  •  ESSENTIAL CONTROLS BEFORE PASSTHROUGH

1. CPU / motherboard must be IOMMU

The implementation of Intel IOMMU is known as VT-d. AMD’s performance of IOMMU is known as AMD-Vi.

2. IOMMU GROUPS

Any material passed through needs to be in its IOMMU group cannot share a group with other material (unless it will also pass through the same time). If a device is in a group of tools that we do not want to go through, you have the Enable Override PCIe ACS in Settings / VM Manager and restart the system.

❖    PASSING THROUGH THE GPU
❖    PASSING THROUGH THE SOUND
❖    FIXING DEMONIC SOUND
❖    THREE COMMON GPU PASSTHROUGH PROBLEMS AND HOW TO SOLVE THEM
❖    MAKING NON-EFI COMPATIBLE GPU EFI COMPATIBLE
❖    PASSING THROUGH A USB CONTROLLER

FAQ (Frequently Asked Questions)

How to remote access with amd video card in unraid windows 10

Following the steps on how to remote access with amd video card in unraid       windows 10:

1. The first step is to Right-click on your desktop and selects Graphics Properties or Intel graphics settings. This will open the Control Panel Intel Graphics and Media. Click on Advanced Mode and then press OK.
2. In the next step, a window will open, click on the 3D tab, and set your 3D performance preferences. Now, click on Apply.
3. Click the Power tab, and set the power planes at peak performance. If you sometimes do with your laptop, only work on battery, choose the battery from the upper right corner, and set maximum performance. Click Apply.
4. Close the Intel Graphics Control Panel and right-click on your desktop again. Then select the control panel for your dedicated GPU (usually NVIDIA or ATI / AMD Radeon).
5. For NVIDIA cards, click Edit Image Settings with Preview, select Use my preferences focus on: performance, and click Apply.
6. Click Manage 3D Settings and open the dropdown menu to the global settings. Select the NVIDIA high-performance processor as your favorite graphics processor and click Apply.
7. If your graphics card, go to Graphics> 3D and drag on performance, so it is set for optimum performance. Click Apply. NOTE: This feature may not be available on all ATI models.
8. Suppose your Catalyst Control Center is the Switchable Graphics tab to go and browse to locate and define seratovideo.exe for high performance. Click Apply. Also, do the same for your host software.
9. Restart your computer, open the software, and play videos! If you can not open Serato Video and still the message appears that you are using an Intel graphics card, then you need to go www.amd.com and download the latest drivers.

If a windows 10vm sleeps in Unraid, how do you wake it up

So, there are sleeping, the power-saving hibernation, and. Hibernation is one thing I recommend to disable the wiki, as I do not see the point because the physical hardware underneath is still running anyway. Sleep can be annoying if you go through USB devices because when the virtual machine is asleep, he is in a state of suspension, which means you would have to take the WebGUI (by moving the mouse or pressing the keyboard you help).
However, if you wish to turn off the monitor after a period of inactivity, that is possible within Windows without using hibernation or sleep.

How to install Windows 10 in a Virtual Machine on Ubuntu Linux

There are many virtual machines available for Linux / Ubuntu, but we will use Oracle VM VirtualBox. VirtualBox is a free virtualization and open source software from Oracle.

1. Add VirtualBox in Ubuntu repository
Go to Start> Software & Updates> Other software> button “Add …”
Enter the following line APT in the entrance area, replacing <mydist> with your distribution (in our case, it was xenial).:
deb https://download.virtualbox.org/virtualbox/debian <mydist> contrib
Replace <mydist> with your distribution (in my case, it was xenial).
Enter the password and dialogue nearby.
2. Download the Oracle signing
Download Oracle public key for apt-secure:
Here Debian 8 (“Jessie”) / Ubuntu 16.04 (“Xenial”) and later
You may have to the right click on the link and select “Save As.”
3. Apply Oracle signing
Go to the terminal and enter the following command:
Sudo apt-key oracle_vbox_2016.asc;
In my case, the file is in the download folder, so this command:
Sudo apt-key ~ / Downloads / oracle_vbox_2016.asc;
Hopefully, you’ll get this output:
4. Install VirtualBox
Open the terminal. Go to Start> Terminal.
Sudo apt-get update
Sudo apt-get install VirtualBox-5.2
5. Download the image of Windows 10 ISO
Visit Microsoft Media creation of this link tool.
Now, Download the “Microsoft Media Creation Tool.”
Run the tool from a Windows computer and follow the ISO creation steps:
Accept Terms and Conditions
Select “Create installation media (USB flash drive, DVD, or ISO file) to another PC.
Select the language, architecture, and editing.
When asked the media to use, select “ISO file
Wait until the process is complete.
When he proposed to burn ISO to CD, click “Finish.”
Find the new file “Windows.iso” and copy or send it to your computer Linux / Ubuntu.
6. Run Windows 10
Select Windows 10 OS from the main screen VirtualBox and click “Start.”
Enter the registration key Windows.
Windows installation screen will be displayed.
Wait for the Windows installation is complete.

Verdict

So, we have tried to give a detailed explanation of how to install windows 10vm unraid and setup unraid windows 10vm.

We hope you will like it!
